2N IP Verso - I;O

Installation manual 2N® IP Verso
197 / 241
•
•
•
•
•
I/O
The I/O module (Part No.9155034) is one of the2N
®
IP Versointercom elements and is used for
extending the number of inputs and outputs.
The module contains two2N
®
IP Versobus connectors.
These two connectors are fully interchangeable and can be used both as inputs from the
main unit and outputs to other modules.
If this module is the last one on the bus, one of the connectors remains unconnected.
The module package includes an 80 mm long interconnecting cable.
The inputs / outputs are addressed as follows:<module_name>.<input/output_name>,
e.g. module5.relay1.The module name is configured in theModule name parameter in
theHardware / Extenders menu.
RELAY1 RELAY1 terminals with accessible 30 V / 1 AAC/DC NO/NC contact
RELAY2 RELAY2 terminals with accessible 30 V / 1 AAC/DC NO/NC contact
