68 78-9000-5020-0 Rev C
Item Specification
Typical Battery Life Normal Output Power level: 50 hours
High Output Power level: 10 hours
Typical transmitter specied battery life (listed above) is increased by 40%
when using the 2200RB Rechargeable Battery (12 volt). Using the 2200RB
bypasses the alkaline batteries.
Maximum Output Power level: 4 hours (Maximum Output Power level
achieved using 2200RB Rechargeable Battery.)
External DC Power 9-18V DC, 3A MAX
Standard IP54
Regulatory FCC compliant, FCC Part 15
Operating Temperature 4°F to 122°F (-20°C to 50°C)
Storage Temperature -4°F to 158°F (-20°C to 70°C)
Rechargeable Battery Fuse 5 Amp / 32 Volt
Littelfuse MINI
®
Blade # 0297005
Cigarette Lighter Adapter
Cable Fuse
4 Amp/Fast Blow 250V
