PRODUCT CONFIGURATION (PART NAMES), INSTLLATION AND PRECAUTIONS
2.1. Unpacking
 The balance is a precision instrument. Unpack the balance carefully. Keep the packing material
to be used for transporting the balance in the future.
 The packing contents depend on the balance model. See the illustrations to confirm that everything is
contained.
Aluminum pan support
for FZ-5000i and FX-5000i
1
2
3
Assemble the breeze break as shown below.
Follow the numbered sequence.
4
Weighing pan
Pan support
Main unit
Display
Bubble spirit
level
Leveling
When installing the pan support to the
balance, handle it carefully so that the
diaphragm is not deformed.
Weighing pan
Pan support
The FZ- i WP/FX- i WP series have a different configuration
.
Pan support boss
Diaphragm
for waterproof
How to assemble the breeze break
(included with all models of FZ-i/FZ-iWP/FZ-GD series, and FX-120i/200i/300i/500i,
FX-120iWP/200iWP/300iWP and FX-120GD/200GD/300GD)
Keys
