VCCX2 Controller Technical Guide
PART DESCRIPTION ORION AAON
VCCX2 Controller OE338-26B-VCCX2 ASM01698
VCC-X EM1 Expansion Module OE336-23-VCCXEM1 ASM01691
Refrigerant System Module for VFD Compressors OE370-26-RSMV ASM01686
Refrigerant System Module VFD Compressors - Heat Pump OE370-26-RSMV-HP ASM01693
Refrigerant System Module for Digital Compressors OE370-26-RSMD ASM02201
Refrigerant System Module for VFD Compressors (RSMZ) N/A ASM02351
Subcool Monitor Controller N/A ASM02350
12 Relay E-BUS Expansion Module OE358-23E-12R ASM01873
Building Static Pressure Sensor OE258-01 ASM01832
CommLink 5 Communications Interface OE361-13 ASM01874
Duct Static Pressure Sensor & Pickup Tube OE271 & OE290 ASM01640 & ASM02242
Duct Temperature Sensor - 6” or 12” OE230 / OE231 G051240 / G051250
EBC E-BUS Cable Assembly E-BUS Power & Comm
1.5 Ft, 3 Ft, 10 Ft, 25 Ft, 50 Ft, 75 Ft,
100 Ft, 150 Ft, 250 Ft, and 1000 Foot Spool
EBC-1.5-F, EBC-3-F, EBC-10-F, EBC-
25-F, EBC-50-F, EBC-75-F, EBC-100-F,
EBC-150-F, EBC-250-F, EBC-SPOOL
G029440 (1.5 Ft), G012870 (3 Ft),
G029460 (10 Ft), G045270 (25 Ft),
G029510 (50 Ft), G029530 (75 Ft),
G029450 (100 Ft), G029470 (150 Ft),
V36590 (250 Ft), G018870 (SPOOL)
E-BUS Adapter Hub MS000248 G033970
E-BUS Adapter Hub with 1.5 Ft. EBC Cable HZ-EBC-248 ASM01635
E-BUS Adapter Board OE365-15-EBA ASM01878
E-BUS CO
2
Sensor Space Wall Mounted or Duct Mounted OE256-05 / OE256-07 ASM01829 / ASM01831
E-BUS Digital Room Sensor - LCD - Temp. or Temp & RH OE217-02 / OE217-03 ASM01819 / ASM01820
E-BUS Digital Room Sensor - No LCD Display - Temp & RH OE217-04 ASM02221
E-BUS Horizontal Outside Air Temperature & RH Sensor OE265-15 ASM01836
E-BUS Vertical Outside Air Temperature & RH Sensor OE265-16 ASM01838
E-BUS Return Air Temperature & RH Sensor OE265-17 ASM01840
E-BUS CO
2
Return Air Sensor Emulator Board OE365-07-EBSE ASM01623
E-BUS CO
2
Space Sensor Emulator Board OE365-06-EBSE ASM01622
E-BUS Outdoor Air Temp/RH Sensor Emulator Board OE365-05-EBSE ASM01697
E-BUS Return Air Temp/RH Sensor Emulator Board OE365-04-EBSE ASM01621
E-BUS Space Temp/RH Sensor Emulator Board OE365-03-EBSE ASM01696
GPC-XP Controller OE338-23-GPCXP ASM01868
IP Module Kit OE415-02 ASM01902
MHGRV-X Controller / Reheat Expansion Module OE377-26-00059 / OE377-01-00059 ASM01670 / ASM01687
MiniLink Polling Device 5 OE364-23-OR ASM01626
MODGAS-X Controller OE377-26-00058 ASM01668
MODGAS-XWR2 Controller OE377-26-00060-1 ASM01695
Modular Service Tool SD - Operator Interface OE391-12 ASM01895
Modular System Manager SD - Operator Interface OE392-12 ASM01901
Outdoor Air Temperature Sensor OE250 G042230
PREHEAT-X Controller / PREHEAT-X-EXT Controller OE377-26-00061 / OE377-26-00061-1 ASM01688 / ASM01689
Standard Room Sensor - Plain or W/ Override OE210 / OE211 ASM02227 / ASM01638
Standard Room Sensor - W/ Slide Adjust or Override & Slide OE212 / OE213 ASM01642 / ASM01643
Strap-On Temperature Sensor Kit OE233 ASM01624
Suction Pressure Sensor OE275-01 ASM02222
System Manager TS-L (Touch Screen - Limited Access) OE392-11 ASM01900
USB-Link 2 Kit OE366 ASM02244
OVERVIEW
Part Number Cross Reference
