AAON Orion VCCX2 User Manual

114
VCCX2 Controller Technical Guide
Air Balance Screens
Refer to the following map when navigating through the Air
Balance Screens. From the Air Balance Screen, press <ENTER>.
Air
Balance
Max Fan
10.0 vdc
MAXIMUM FAN VOLTAGE
0.0 to 10.0 vdc
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is 10.0.
Min Fan
0.0 vdc
MINIMUM FAN VOLTAGE
0.0 to 10.0 vdc
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is 0.0.
Max Exh
10.0 vdc
MAXIMUM EXHAUST VOLTAGE
0.0 to 10.0 vdc
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is 10.0.
Min Exh
10.0 vdc
MINIMUM EXHAUST VOLTAGE
0.0 to 10.0 vdc
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is 10.0.
APPENDIX B
-
VCCX2 LCD SCREENS
Air Balance Screens and Factory Test Mode Screen
