VCCX2 Controller Technical Guide
RSMZ TREND LOG BIT STRINGS - COMPSTAT
Item Bit Value Description
1Comp1Stat
2Comp1Stat
3Comp1Stat
3Comp2Stat
4Comp1Stat
5Comp1Stat
6Comp1STat
6Comp2Stat
0 1 Congured
1 2 Enabled
2 4 Running
3 8 Failed
4 16 Lockout
5 32 MinRunFlag
6 64 MinRunPending
7 128 MinO󰀨Flag
8 256 MinO󰀨Pending
9 512 StageUpConditionsMet
10 1024 StageDwnConditionsMet
11 2048 StageUpFlag
12 4096 StageDwnFlag
13 8192 CoilTempSatised
Table 9: RSMZ Module Comp Status Trend Log
RSMZ TREND LOG BIT STRINGS - RSM ALARMS
Item Bit Value Description
1RSMAlrms
2RSMAlrms
3RSMAlrms
4RSMAlrms
5RSMAlrms
6RSMAlrms
0 1 LowSuction
1 2 UnsafeSuction
2 4 TripHighDiscPSI_Comp1
3 8 Compressor1_NotRunning
4 16 Compressor2_NotRunning
5 32 LowSuperheat
6 64 HighDischargeTemperature
7 128 DMQ_NoDetect
8 256 ModBusSlaveCommTO
9 512 LowSuctionComp2O󰀨
10 1024 TripHighDiscPSI_Comp2
11 2048 HighSuperheat
12 4096 HighEvapTemp
Table 10: RSMZ Module RSM Alarm Trend Log
SEQUENCE OF OPERATIONS
RSMZ Trend Logs and Trend Log Enumerated Values
