VCCX2 Controller Technical Guide
Features
The VCCX2 Controller is designed with eight analog inputs,
four analog outputs, eight binary inputs, and eight relay outputs
(seven congurable). It also has an on-board BACnet
®
port for
connection to an MS/TP network. The Controller contains a 2 x
8 LCD character display and four buttons that allow for status
and alarm display, force modes, and BACnet
®
conguration.
The VCCX2 Controller can communicate with the Refrigerant
System Module for VFD Compressors, Refrigerant System
Module for VFD Compressors - Heat Pump, Refrigerant System
Module for Digital Compressors, and Refrigerant System
Module for VFD Compressors (RZ or RN-E units with Danfoss
compressors). In addition, the VCC-X EM1 Expansion Module
and 12 Relay E-BUS Expansion Module provides additional
specically dedicated inputs and outputs.
There are also two E-BUS Expansion connectors on the VCCX2
which allow for the connection of the expansion modules listed
above, as well as communicating sensors, and future E-BUS
Modules via modular E-BUS cables. There are presently seven
communicating sensors available. Two of these sensors have
LCD displays: E-BUS Digital Space Temperature Only Sensor or
E-BUS Digital Space Temperature and Humidity Sensor. There
is a communicating E-BUS Space Temperature and Humidity
Sensor with no LCD display as well as an E-BUS Space CO
2
Sensor, and E-BUS Duct CO
2
Sensor, each with no LCD display.
Also available are the E-BUS Horizontal or Vertical Outdoor Air
Temperature and Humidity Sensor and the E-BUS Return Air
Temperature and Humidity Sensor.
The VCCX2 Controller provides for the following applications:
Constant Volume, VAV, Single Zone VAV, Make-up Air, and
Space Temperature Control of High Percentage Outdoor Air.
Other features of the VCCX2 include:
• Controls up to 8 Digital Compressors
• Controls up to 4 sets of tandem VFD Compressors
• Controls up to 12 stages of Heat
• Modulating Cooling Output for Chilled Water Valve
Control
• Modulating Heating Output (Hot Water Valve, Steam
Valve, SCR Electric Heat Control)
• Full Integration with the AAON
®
Refrigerant System
Modules
• Full Integration with the AAON
®
MODGAS-X
Modulating Natural Gas Controller
• Full Integration with the AAON
®
MHGRV-X
Modulating Hot Gas Reheat Valve Controller
• Full Integration with the AAON
®
PREHEAT-X
Controller
• Advanced Dehumidication Capabilities
• Air to Air Heat Pump and Water Source Heat Pump
applications
• Air Flow Monitoring of Outdoor Air, Supply Air,
Return Air, and Exhaust Air Streams with approved
• EBTRON
®
, GreenTrol
TM
, or Paragon Airow
Monitoring Stations
• Air Flow Control of Outdoor Air Damper
• Single Zone VAV Control w/Optional CAV Heating
• Primary/Secondary Heating Control
• Remote Forced Cooling, Heating, and
Dehumidication Control
• Remote Supply Air Temperature Reset Signal
• Adaptive Supply Air Temperature Reset
• Selectable Mode Enable Sensor
• Fan Proving Interlock
• Dirty Filter Alarm
• Emergency Shutdown Input (Smoke Detector/Firestat
or other Shutdown Conditions)
• Drybulb/Wetbulb/Dewpoint Control of Economizer
Operation
• Waterside Economizer Capability
• Building Pressure Control (Direct or Reverse Acting)
• Exhaust Duct Static Control of Exhaust Fan
• Remote Forced Occupied Capability
• Congurable for AAON
®
Return Air Bypass
Applications
• IAQ Economizer Reset
• Title 24 Economizer Certied
• 7-Day, 2-Event-per-Day Scheduling
• 14 Holiday Event Scheduling
• Daylight Savings Time Adjustment
• Trend Logging Capability
• Static Pressure Control for Filter Loading
Applications
• Heat Wheel - On/O Control
• Head Pressure Control
• On-board BACnet
®
port for connection to an MS/TP
network (See Appendix C)
