VCCX2 Controller Technical Guide
Output Override Screens
Refer to the following map when navigating through the Output
Override Screens. From the Output Override Screen, press
<ENTER>.
Output
Override
Relay #1-8
ON, OFF, AUTO
VCCX2 CONTROLLER RELAYS 1-8
Press the <UP> button to change the value.
Default is AUTO.
Fan VFD
-1.0, 0.0-10.0
vdc
SUPPLY FAN VFD
0.0 to 10.0 = Active Force Mode.
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is -1.0 = AUTO.
OA Dampr
-1.0, 0.0-10.0
vdc
OUTDOOR AIR DAMPER VFD
0.0 to 10.0 = Active Force Mode.
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is -1.0 = AUTO.
Mod Heat
-1.0, 0.0-10.0
vdc
MODULATING HEATING
0.0 to 10.0 = Active Force Mode.
Press the <UP> and <DOWN> buttons to increase and decrease the
value. Default is -1.0 = AUTO.
Mod Cool
-1.0, 0.0-10.0
vdc
MODULATING COOLING
0.0 to 10.0 = Active Force Mode.
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is -1.0 = AUTO.
Exhaust
-1.0, 0.0-10.0
vdc
EXHAUST FAN
0.0 to 10.0 = Active Force Mode.
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is -1.0 = AUTO.
RA Dampr
-1.0, 0.0-10.0
vdc
RETURN AIR DAMPER
0.0 to 10.0 = Active Force Mode.
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is -1.0 = AUTO.
RA Bypas
-1.0, 0.0-10.0
vdc
RETURN AIR BYPASS
0.0 to 10.0 = Active Force Mode.
Press the <UP> and <DOWN> buttons to increase and decrease
the value. Default is -1.0 = AUTO.
APPENDIX B
-
VCCX2 LCD SCREENS
Output Override Screens
