VCCX2 Controller Technical Guide

If the controller is congured to have any of the above air ow

sensors, but the controller does not detect that the sensor is

connected, then the applicable alarm will occur. If the sensor

is properly detected after the unit has alarmed, the alarm will

be cleared.

Missing Expansion Module Alarm

Preheat-X Board Missing

EM1 Expansion Missing

RSM Modules #1 - #4 Missing

Reheat Board Missing

ModGas Board Missing

12 Relay Board Missing

If the controller is congured to have any of the above Expansion

Boards (Modules), but the controller does not detect that board,

then the applicable alarm will occur. If the board is properly

detected after the unit has alarmed, the alarm will be cleared.

SEQUENCE OF OPERATIONS

Alarm Detection and Sensor Failure Alarms

Default Chapter3
