Abarth 595 - SEATS

15
SEATS
FRONTSEATS
Lengthwiseadjustment
Lift lever (1) fig. 9 and push the seat
forwards or backwards: in the driving
position, you should be able to rest
your arms on therim of the steering
wheel.
9)10)11)
2)
9AB0A0010C
Heightadjustment
(where provided)
Move lever (3) fig. 10 up or down until
the required heightis reached.
10AB0A0012C
Backrestangleadjustment
Turn knob (2) fig. 11until the required
position is reached.
11AB0A0011C
Recliningthebackrest
3)
To fold the backrest over, adjust lever
(4) fig. 12 (movement A) and push
the backrest forwards until it locks
(movement B).
Then release lever(4) and, pushing on
the backrest, slidethe seat forward
(movement C).
12AB0A0013C
Driversideand passengerside,
withpositionmemory
To bring back theseat in its initial
position proceed as follows:
slide the seat backwards pushing on
the backrest, untilthe seat is locked
(movement E);
adjust lever (4) fig. 12 (movement E);
raise the backrest(movement F) until
you hear the lockclick.
WARNING Using lever (4) fig. 12 before
locking the seat inits initial position will
cause the initial seat position to be lost.
In this case the position of the seat
must be restoredthrough lengthwise
adjustment lever (1) fig. 9.
