Abarth 595 - Rear-View Mirrors

19
REAR-VIEW
MIRRORS
INTERIORMIRROR
The mirror is fitted with a safety device
that causes its release in the event of a
violent impact withthe passenger.
Lever (1) fig. 20 canbe used to move
the mirror to two different positions:
normal or anti-glare.
20AB0A0019C
ELECTROCHROMIC
REAR-VIEWMIRROR
(where provided)
Some versions have an electrochromic
mirror with automatic antiglare function.
There is an ON/OFF button
on the lower part of the mirror
for activating/deactivating the
electrochromic function. When the
function is active, aLED on the mirroris
active. When reverse is engaged, the
mirror is automatically set for daytime
use.
DOORMIRRORS
Proceed as follows:
21AB0A0020C
select the mirror using selector (2)
fig. 21;
adjust the mirror using the joystick (1)
fig. 21 in the four directions.
Foldingthemirrors
When required (for example when
the mirror causesdifficulty in narrow
spaces ) it is possible to fold the mirrors
manually moving them from the open
position (A) to the closed position (B)
fig. 22.
15)16)
22AB0A0021C
WARNING
15) When driving, thesemirrors must
always be in the open position.
16) As door mirrors are curved, they may
slightly alter the perception of distance.
