Abarth 595 - SOFT TOP

31
keep the button (2) fig. 34 pressed
so that the roof closes completely in
stages
after full closing, wait for the sunroof
motor to stop.
EMERGENCYOPERATION
If the electrical device for moving the
roof fails, the sunroof can be moved
manually proceeding as described
below:
35AB0A0040C
for manual activation remove the
protective cap (1) fig. 35 from its
housing which is located on the internal
covering behind the sunshade
take the hex wrench provided from
the tool bag in theboot
insert the key provided into the slot
(2) and turn it clockwise to open the
roof or anticlockwise to close the roof.
WARNING
23) When leaving the car, always remove
the key from the ignition device to avoid
the riskof injury to those still inside the
car due to accidental operation of the
sunroof. Improper use of the roof can be
dangerous. Before and during operation,
always checkthat no-one is exposed to
the riskof being injured by the moving
sunroof or by objects getting caught or hit
by it.
IMPORTANT
9) Do not open the sunroof if there is snow
or ice on it: you maydamage it.
10) You are advised to use the sunroof
only at "spoiler" position if a transverse
roof rackis fitted.
SOFTTOP
(where provided)
The 595C versionis provided with an
automatically actuated electric soft
top. The top can be opened and
closed using the controls inside the car
located near the ceiling light fig. 38
or the remote control buttons (while
opening and for thehorizontal part
only).
The soft top can be automatically
opened from the closed position to
the spoiler positionfig. 36, and from
this position to thefully open position
fig. 37.
36AB0A0293C
Proceed as follows:
