Abarth 595 - SCHEDULED SERVICING

113
close the bulb holder making sure
the retaining device is correctly locked;
screw in the two fastening screws
and reinstall the guard caps.
NUMBERPLATELIGHTS
To replace the bulbs, proceed as
follows:
operate in the point shown by the
arrow fig. 113 andremove the lens;
change the bulb, releasing it from the
side contacts;
fit the new bulb andmake sure that
it is correctly clamped between the
contacts;
113AB0A0099C
then refit the lens.
WARNING
130) Due to the high power supply
voltage, gas discharge bulbs (Xenon)
should only be replaced by specialised
technicians: dangerof death!Contact an
Abarth Dealership.
REPLACING
INTERIORBULBS
For the type of bulb and power rating,
see paragraph "Replacing a bulb".
INTERIORCEILINGLIGHT
To replace the bulb, proceed as
follows:
using the screwdriver provided,
extract the ceilinglight (1) fig. 114
working in the point shown by the
arrow;
114AB0A0100C
open cover (2) fig. 115 as shown and
then change bulb(3) fig. 116 it from the
side contacts;
insert the new bulband make sure
that it is correctly clamped between the
contacts;
115AB0A0101C
116AB0A0102C
close the cover (2)then refit the lens
(1).
BOOTCOURTESYLIGHT
To replace the bulb, proceed as
follows:
open the boot;
using the screwdriver provided,
extract the ceilinglight (1) fig. 117
working in the point shown by the
arrow;
