Operation Manual / 4 Product description / A100-M axial

12 Spare parts / 12.1 Ordering spare parts

12 Spare parts

12.1 Ordering spare parts

CAUTION

Spare part storage

All spare parts that were ordered together with the turbocharger must be

kept intact and ready for use.

u Carefully clean any rusted parts and grease them.

Please quote the following data when making queries and ordering spare parts:

(Locations of the rating plates →7)

¡ Turbocharger type

¡ Serial number (HT……)

¡ Designation and part number.

Spare parts can be ordered from any ABB Turbocharging Service Station.

u If different model variants are not taken into account in this document, contact an ABB

Turbocharging Service Station.

u Dispose of placed and unusable parts in an environmentally-friendly and professional

manner in accordance with the local regulations.

u Dispose of the packaging of new parts in an environmentally-friendly and professional

manner in accordance with the local regulations.

Required customer spare part set (97070)

For the operations described in the Operation Manual, the customer spare part set (97070)

is required. These parts are only available as part of the complete set.

Part number Designation Quantity

42012 O-ring 1

42041 Gasket 1

42045 Gasket 2

42059 / 42064 Hexagon-head screw 2

56014 Hexagon-head screw 2

56015 Locking washer 2

57005 Hexagon-head screw 5

61037 Hexagon nut 3

61069 Hexagon-head screw 3

77015 Socket screw 3

77040 O-ring 1

86506 O-ring (speed sensor) 1

Table51: Customer spare part set (97070)

Page 103 / 108

ABB A170-M Series Original Operation Manual
