ABB A170-M Series Original Operation Manual

Operation Manual / 4 Product description / A100-M axial
12 Spare parts / 12.2 View of turbocharger with part numbers
© Copyright 2019 ABB. All rights reserved. HZTL4033_DE Revision C February 2019
Turbocharger
Part number Designation
51001 Gas inlet casing, radial
56001 Nozzle ring
56014 (in customer spare part set) Hexagon-head screw
56015 (in customer spare part set) Locking washer
57001 Cover ring
57005 (in customer spare part set) Hexagon-head screw
61001 Gas outlet casing
61037 (in customer spare part set) Hexagon nut
61050 Gasket
61069 (in customer spare part set) Hexagon-head screw
63000 Turbine diffuser
68001 Foot, compressor end
68002 Foot, turbine end
68003 Sliding block
72000 Compressor casing
77015 (in customer spare part set) Socket screw
77000 Wall insert
77040 (in customer spare part set) O-ring
79000 Diffuser
81000 Filter silencer
82000 Radial air suction branch
Table52: Turbocharger with part numbers
