ABB A170-M Series - Fig. 4: Locations of the Rating Plates; Locations of the Rating Plates

Operation Manual / 4 Product description / A100-M axial
1 Introduction / 1.6 Locations of the rating plates
© Copyright 2019 ABB. All rights reserved. HZTL4033_DE Revision C February 2019
1.6 Locations of the rating plates
Fig.4: Locations of the rating plates
One rating plate each is attached on the left and the right side of the foot of the turbochar-
ger.
On turbochargers with insulation from ABB Turbo Systems, at least one additional rating
plate is attached to the insulation of the gas outlet casing.
