ABB A43 User Manual

Communication with Modbus
2CMC48001M0201 151 A43/A44
Revision: C User Manual
Quantity
OBIS code
Apparent power L3
1.0.140. 7.0.255
Power factor total
1.0.13.7.0.255
Power factor L1
1.0.33.7.0.255
Power factor L2
1.0.53.7.0.255
Power factor L3
1.0.73.7.0.255
Harmonic voltage L1
1.0.32.7.124.255
Harmonic voltage L2
1.0.52.7.124.255
Harmonic voltage L3
1.0.72.7.124.255
Harmonic voltage L1-L2
1.0.134.7.124.255
Harmonic voltage L2-L3
1.0.135.7.124.255
Harmonic voltage L1-L3
1.0.136.7.124.255
Harmonic current L1
1.0.31.7.124.255
Harmonic current L2
1.0.51.7.124.255
Harmonic current L3
1.0.71.7.124.255
Harmonic current Neutral
1.0.91.7.124.255
Inactive (deactivates the alarm)
1.128.128.128.128.128
Thresholds
The Thresholds registers are used to read and write the ON and OFF threshold
registers
values for an alarm. The scaling is the same as where the quantity appears in the
normal mapping tables. The first (lowest) 4 registers are the ON threshold and the
last 4 registers are the OFF threshold. Data type is signed 64 bit integer.
Delays registers
The Delays registers are used to read or write the ON and OFF delays for an
alarm. The delay is expressed in milliseconds. The first (lowest) 2 registers are the
ON delay and the last 2 registers are the OFF delay. Data type is unsigned 32 bit
integer.
Actions registers
The Actions registers are used to read or write the actions to be performed when
an alarm triggers. The first (lowest) register holds the actions to perform. The
