7/8
Input Counter 3
Inp.Ctr 3
1 hours
8/8
Input Counter 4
Inp.Ctr 4
1 hours
4. Configure the desired channels.
When a configuration has been made, a reset may be required in order to
perform a new configuration. To reset the intervals, toggle down to the reset
page and perform a reset the same way as performing a setting.
4.1.17 Setting Demand
The demand function enables measuring of up to 50 values (channels) . Step 1-
6 are general for the function and step 7-9 are specific for each channel.
To set the demand, perform the following steps:
1. Choose the Settings icon in the main menu, press .
2. Choose “Demand” (Demand on the display), press .
3. Set the period. The available choices are day, week and month. If choosing
day, the starting point will be now and the ending point will be 00:00. If
choosing month, the starting point will be now and the ending point will be
the first of next month at 00:00. If choosing week, the starting point will be
now and the ending point will be the set day at 00:00. If choosing week,
press to get to the page where the day is set. Press .
4. Set the interval that shall be measured. Press to continue.
5. Set the subinterval that shall be measured. Press to continue.
6. Set if the previous settings shall be reset. Press to continue.
7. Set the quantity that shall be measured. Press to continue.
8. Set the demand type. Press to continue.
9. The demand level will be set automatically.
The first channel is now set. To set the next channel, repeat step 3-9. Up to
50 channels can be set.
4.1.18 Resetting Resettable Registers
To reset registers, perform the following steps:
1. Choose the Settings icon in the main menu, press .
2. Choose “Resettable registers” (Rst.Reg on the display), press .
3. The display will show the different registers to reset. Depending on the
meter type, the available choices are:
Register
On the display
Active Energy Imported Total
Act.Imp
Active Energy Exported Total
Act.Exp
Reactive Energy Imported Total
Rea.Imp
Reactive Energy Exported Total
Rea.Exp
Reset all
All
4. Toggle through the pages and reset the desired registers.
