ABB A43

Meter Settings
2CMC48001M0201 33 A43/A44
Revision: C User Manual
4.1 Settings and Configurations
Configurable
Depending on the meter type, all or a subset of the following functions can be
functions
configured:
•
Clock
•
Ratios
•
Wires
•
Pulse output (Pul.Out.) on display
•
I/O Pulse output (Pul.Out.) on display
•
Alarm
•
Currency/CO
2
(Curr/CO2) on display
•
M-Bus
•
RS-485
•
IR Side
•
Wireless (W-less on display)
•
Upgrade Consent (Upgr.Cons) on display
•
Pulse LED (Puls.LED) on display
•
Tariff
•
Previous Values (Prev. Val. on display)
•
Load profile (Load Pro on display)
•
Demand
• Resettable registers (Rst.Rg on display)
Setting a value When setting a value, the button is used to activate the set option. The and
buttons are used to change the options that can be set, such as on or off. If the
set option involves setting a number, for example a alarm limit, the button is
used to increase a digit, and the button is used to decrease a digit. The
button is used to toggle between digits.The option/digit that is active for setting is
marked with a underscore. When the underscore on the last option has dissa-
peared, the setting has been performed.
4.1.1 Setting Date
To set the date, perform the following steps:
1. Choose the Settings icon in the main menu, press .
2. Choose “Clock”, press .
3. The display will now show the date.
4. Set the date.
