4. Press once to get to the next menu. The display will show the frequency.
The interval that can be set is 0-999999 imp/kWh or 0-999999 imp/MWh.
Set the frequency and quantity.
5. Press once to get to the next menu. The display will show the
pulse length in milliseconds. The interval for the pulse length is from
10 to 990ms. Set the pulse length.
6. Press once to get to the next menu. The display will show the setting for
pulse output 1. Depending on the meter type, the available choices are:
4 configurable I/Os
4 static I/Os
1 static I/O
No output
No output
No output
Out 1
Out 1
Out 1
Out 2
Out 2
-
Out 3
-
-
Out 4
-
-
Note – If choosing an I/O that is not pulse output configured, the option is set to “no
output” when pressing the button.
7. The first pulse output is now fully configured. Depending on the meter
type, up to four pulse outputs can be set. If your meter supports multiple
pulse outputs, use to toggle down to the remaining pulse outputs and
set them the same way as pulse output 1.
4.1.6 Setting I/O
To set the I/O, perform the following steps:
1. Choose the Settings icon in the main menu, press .
2. Choose “I/O”, press .
3. The display will now show I/O 1. To change I/O, use or . To set an
I/ O, press the button. Depending on the meter type, different choices
can be made for the I/O, see table 4:2.
Table: 4:2
I/O
Available choices
4 configurable I/Os
•
Input
•
Alarm out
• Communication out (Comm.out on display)
• Pulse out (Pul.out on display)
•
Tariff out
1
•
Always on
•
Always off
4 static I/Os
2
•
Alarm out
• Communication out (Comm.out on display)
• Pulse out (Pul.out on display)
•
Tariff out
3
•
Always on
•
Always off
