ABB A43

Meter Settings
A43/A44 42 2CMC48001M0201
User Manual Revision: C
Protocol
Access
Upgrade
Send
Reset
Parity
Baudrate
Address
Inter
Inactivity
level
mode
Status
password
octet
timeout
Info
timeout
(ms)
(ms)
EQ-Bus
-
-
-
Yes, No
-
1200,
(when
2400,
used
4800,
through
9600,
IR-Side)
19200
4.1.12 Setting Upgrade Consent
Upgrade Consent can be set to Allowed or Not Allowed. Setting it to Allowed
means you agree to updates of the meter. Setting it to Not Allowed means no
upgrades will take place.
To set Upgrade Consent, perform the following steps:
1. Choose the Settings icon in the main menu, press .
2. Choose “Upgrade Consent” (Upgr.Cons on the display), press .
3. Press to set Upgrade Consent.
4.1.13 Setting Pulse LED
To set pulse LED, perform the following steps:
1. Choose the Settings icon in the main menu, press .
2. Choose “Pulse LED” (Puls.LED on the display), press .
3. Press to set the type of energy, active or reactive, that the LED shall
indicate on.
4.1.14 Setting Tariff
The tariff source can be set to input, clock or communication. To set the
tariffs, perform the following steps:
Step
Input
Clock
Communication
1
Choose the Settings icon in
Choose the Settings icon in
Choose the Set-
the main menu, press .
the main menu, press .
tings icon in the
main menu, press
.
2
Choose “Tariff”, press .
Choose “Tariff”, press .
Choose “Tariff”,
press .
