ABB A43

Meter Settings
A43/A44 34 2CMC48001M0201
User Manual Revision: C
4.1.2 Setting Time
To set the time, perform the following steps:
1. Choose the Settings icon in the main menu, press .
2. Choose “Clock”, press .
3. The display will now show the date. Press to get to the time-menu.
4. Set the time.
4.1.3 Setting Ratios
To set the ratios, perform the following steps:
1. Choose the Settings icon in the main menu, press .
2. Choose “Ratios”, press .
3. The display will show the quantity Current (CT on the display) and the
ratio. To change the ratio, press . See table 4:1 for interval.
4. Press . The display will show the quantity Voltage (VT on the display)
and the ratio. To change the ratio, press . See table 4:1 for interval.
Table: 4:1
Option
Interval
Transformer Current (CT on the dis-
1-9999/1-9
play)
Transformer Voltage (VT on the dis-
1-999999/1-999
play)
4.1.4 Setting Wires
The meter can either use three wires TPE or four wires TPE+N. To set the
number of wires, perform the following steps:
1. Choose the Settings icon in the main menu, press .
2. Choose “Wires”, press .
3. The display will now show the wire configuration used by the meter.
4. Set the number of wires.
4.1.5 Setting Pulse Output
To set the pulse output, perform the following steps:
1.
Choose the Settings icon in the main menu, press .
2.
Choose “Pulse out” (Pul.out on the display), press .
The display will show what type of energy is measured on pulse output 1.
Depending on meter type, the available choices are:
Act.Nrg.Imp on the display
Active energy imported
Act.Nrg.Exp on the display
Active energy exported
React.Nrg.Imp on the display
Reactive energy imported
React.Nrg.Exp on the display
Reactive energy exported
Inactive on the display
Inactive
3.
Set the energy type.
