Communication with M-Bus
2CMC48001M0201 251 A43/A44
Revision: C User Manual
10.4.4.1 Example of readout of log data
Readout of Net Quality Log with date and time specified as input
Send Nke.
10 40 fe 3e 16
Meter Responds with
E5 E5
Read request net quality log with Offset -1.
68 12 12 68 73 fe 51 ce c0 80 80 00 ed ff f9 30 01 02 03 22 12 11 b0 16;Read
net quality log with offset value -1. Date and Time spciefied as input, 22-12-
2011 01:02:03
Meter Responds with E5.
E5.
Send Req UD2.
10 7B FE 79 16.
Meter responds with long frame data for net quality Log:
68 88 88 68 08 00 72 00 00 00 00 42 04 20 02 16 2a 00 00 ; Header
Information 02 ff f9 b5 00 e1 07;Event Type net quality Log
0e ed b9 00 21 47 23 06 01 10 ;Date and Time 10.01.06 23:47:21
04 a0 00 dd 03 00 00 ;Duration
02 ff f9 b5 00 de 07 ;Event Type net quality Log
0e ed b9 00 21 47 23 06 01 10 ;Date and Time 10.02.06
23:47:21 04 a0 00 dd 03 00 00 ;Duration
02 ff f9 b5 00 f0 03 ;Event Type net quality Log
0e ed b9 00 11 47 23 06 01 10 ;Date and time 10.02.06
23:47:11 04 a0 00 e7 03 00 00 ;Duration
02 ff f9 b5 00 e8 03
0e ed b9 00 11 47 23 06 01
10 04 a0 00 e7 03 00 00
02 ff f9 b5 00 e2 07
0e ed b9 00 11 47 23 06 01
10 04 a0 e7 03 00 00
1f 70 16;1F indicates there are more frames to follow.
