ABB A43

Communication with M-Bus
A43/A44 226 2CMC48001M0201
User Manual Revision: C
Byte No.
Size
Value
Description
164
1
xx
VIFE status
165-170
6
xxxxxxxxxxxx
Active imported energy, tariff 3
171
1
CE
DIF size, 12 digit BCD, storage number bit 0
172
1
80
DIFE, tariff bits 0-1, storage number bit 1-4
173
1
10
DIFE, tariff bits 2-3, tariff 4
174
1
84
VIF for units kWh with resolution 0,01kWh
175
1
xx
VIFE status
176-181
6
xxxxxxxxxxxx
Active imported energy, tariff 4
182
1
CE
DIF size, 12 digit BCD, storage number bit 0
183
1
90
DIFE, tariff 1, storage number bit 1-4, unit bit 0
184
1
40
DIFE, unit bit 1
185
1
84
VIF for units kvarh with resolution 0,01kvarh
186
1
xx
VIFE status
187-192
6
xxxxxxxxxxxx
Reactive imported energy, tariff 1
193
1
CE
DIF size, 12 digit BCD, storage number bit 0
194
1
A0
DIFE, tariff 2, storage number bit 1-4, unit bit 0
195
1
40
DIFE, unit bit 1
196
1
84
VIF for units kvarh with resolution 0,01kvarh
197
1
xx
VIFE status
198-203
6
xxxxxxxxxxxx
Reactive imported energy, tariff 2
204
1
CE
DIF size, 12 digit BCD, storage number bit 0
205
1
B0
DIFE, tariff 3, storage number bit 1-4, unit bit 0
206
1
40
DIFE, unit bit 1
207
1
84
VIF for units kvarh with resolution 0,01kvarh
208
1
xx
VIFE status
209-214
6
xxxxxxxxxxxx
Reactive imported energy, tariff 3
215
1
CE
DIF size, 12 digit BCD, storage number bit 0
216
1
80
DIFE, tariff bits 0-1, storage number bit 1-4, unit bit 0
217
1
50
DIFE, tariff 4, unit bit 1
218
1
84
VIF for units kvarh with resolution 0,01kvarh
219
1
xx
VIFE status
220-225
6
xxxxxxxxxxxx
Reactive imported energy, tariff 4
226
1
1F
DIF, more records will follow in next telegram
227
1
xx
CS checksum, calculated from C field to last data
228
1
16
Stop character
10.3.9 Example of the 9th telegram (all values are hexadecimal
This example telegram contains the most recent snapshot of previous values,
con-tinued from telegram 8. Second most recent snapshot would be sent out in
10th and 11th telegram, and so on.
