ABB A43

Communication with M-Bus
2CMC48001M0201 225 A43/A44
Revision: C User Manual
Byte No.
Size
Value
Description
88-93
6
xxxxxxxxxxxx
Active imported energy, L2
94
1
4E
DIF size, 12 digit BCD, storage number bit 0
95
1
84
VIF for units kWh with resolution 0,01kWh
96
1
FF
VIFE next byte is manufacturer specific
97
1
83
VIFE L3
98
1
xx
VIFE status
99-104
6
xxxxxxxxxxxx
Active imported energy, L3
105
1
CE
DIF size, 12 digit BCD, storage number bit 0
106
1
40
DIFE, Unit 1
107
1
84
VIF for units kWh with resolution 0,01kWh
108
1
FF
VIFE next byte is manufacturer specific
109
1
81
VIFE L1
110
1
xx
VIFE status
111-116
6
xxxxxxxxxxxx
Active exported energy, L1
117
1
CE
DIF size, 12 digit BCD, storage number bit 0
118
1
40
DIFE, Unit 1
119
1
84
VIF for units kWh with resolution 0,01kWh
120
1
FF
VIFE next byte is manufacturer specific
121
1
82
VIFE L2
122
1
xx
VIFE status
123-128
6
xxxxxxxxxxxx
Active exported energy, L2
129
1
CE
DIF size, 12 digit BCD, storage number bit 0
130
1
40
DIFE, Unit 1
131
1
84
VIF for units kWh with resolution 0,01kWh
132
1
FF
VIFE next byte is manufacturer specific
133
1
83
VIFE L3
134
1
xx
VIFE status
135-140
6
xxxxxxxxxxxx
Active exported energy, L3
141
1
CE
DIF size, 12 digit BCD, storage number bit 0
142
1
10
DIFE, tariff 1, storage number bit 1-4
143
1
84
VIF for units kWh with resolution 0,01kWh
144
1
xx
VIFE status
145-150
6
xxxxxxxxxxxx
Active imported energy, tariff 1
151
1
CE
DIF size, 12 digit BCD, storage number bit 0
152
1
20
DIFE, tariff 2, storage number bit 1-4
153
1
84
VIF for units kWh with resolution 0,01kWh
154
1
xx
VIFE status
155-160
6
xxxxxxxxxxxx
Active imported energy, tariff 2
161
1
CE
DIF size, 12 digit BCD, storage number bit 0
162
1
30
DIFE, tariff 3, storage number bit 1-4
163
1
84
VIF for units kWh with resolution 0,01kWh
