VIFE-code
Description
E001 1110
Readout request of reactive exported energy load profile
in format energy register values at end of intervals
E010 0000
Readout request of apparent imported energy load profile
in format energy register values at end of intervals
E010 0010
Readout request of apparent exported energy load profile
in format energy register values at end of intervals
E010 0100
Readout request of input 3 counter load profile in format
counter register values at end of intervals
E010 0110
Readout request of input 4 counter load profile in format
counter register values at end of intervals
E010 1000
Readout request of current load profile
E010 1001
Readout request of voltage load profile
E010 1010
Readout request of THD voltage load profile
E010 1011
Readout request of THD current load profile
E010 1100
Readout request of power factor load profile
E010 1101
Readout request of voltage harmonics
E010 1110
System log
E011 0000
Net quality log
E011 0010
Event log
E011 0011
Event type system log
E011 0101
Event type net quality log
E011 0111
Event type event log
E011 1000
Readout request of load profile based on channel number
E100 0nnn
Energy in CO
2
(kg *10
nnn-7
)
E100 1nnn
Energy in currency (currency * 10
nnn-3
)
E101 snnn
Level nnn (binary coding), s=1 for sliding, 0 for non-sliding
10.2.2.9 2:nd manufacturer specific VIFE followed after VIFE 1111 1110 (FE hex):
VIFE-code
Description
E00t opsl
Data status for load profile, t=time change, o = overflow, p = power
outage during interval, s = short interval, l = long interval
10.2.3 Communication process
General The Data Link Layer uses two kinds of transmission services:
Send/Confirm SND/CON
