Installation

A43/A44 24 2CMC48001M0201

User Manual Revision: C

2-wire connection The following diagram shows a 2-wire connection of a transformer connected 3-

phase meter with voltage transformers:

2.4.4 Inputs/outputs

2 outputs, 2

inputs

4 configurable

Inputs/outputs
