Step-by-step drawings for an installation example of standard drive configuration in Rittal
VX25 800 mm wide enclosure (page 229)
•
Air baffles (page 189)
Installing the roof and door (Rittal parts)
This drawing shows a layout tested by ABB.
Door1
Install these gratings as close to each other as possible. Remove the filter mats.2
138 Installation example in Rittal VX25 enclosure
