ABB ACQ580-34 - Diagnostics; Faults and Warning Messages; Leds; Technical Data

￭ Diagnostics
Faults and warning messages
Warning A7AB Extension I/O configuration failure.
LEDs
The extension module has one diagnostic LED.
DescriptionColor
The extension module is powered up.Green
Technical data
Into an option slot on the drive control unitInstallation
IP20 / UL Type 1Degree of protection
See the drive technical data.Ambient conditions
CardboardPackage
Reley outputs (50…52, 53…55)
1.5 mm
2
Maximum wire size
12 V / 10 mAMinimum contact rating
250 V AC / 30 V DC / 2 AMaximum contact rating
1500 VAMaximum breaking capa-
city
Transistor output (42…44)
1.5 mm
2
Maximum wire size
Transistor output PNPType
4 kohmMaximum load
30 V DCMaximum switching
voltage
100 mA / 30 V DC, short-circuit protectedMaximum switching current
10 Hz … 16 kHzFrequency
1 HzResolution
0.2%Inaccuracy
External power supply (40…41)
1.5 mm
2
Maximum wire size
24 V AC / V DC ±10% (GND, user potential)Input voltage
25 W, 1.04 A at 24 V DCMaximum power consump-
tion
CMOD-01 multifunction extension module (external 24 V AC/DC and digital I/O) 219
