Fuses (UL)
UL 248-13 Recognized fuses for branch circuit protection per NEC are listed below. Obey
local regulations.
Ultrarapid (aR, semiconductor) fuses
Input cur-
rent (A)
Drive type
ACQ580-34-
Type French
Style
Type US Style
Type DIN
43653
Type Flush
End
VA
U
n
= 480 V
170M5308170M5608170M5008170M5408690400209240A-4
170M5310170M5610170M5010170M5410690500258302A-4
170M6310170M6610170M6010170M6410690630307361A-4
170M6311170M6611170M6011170M6411690700363414A-4
170M6312170M6612170M6012170M6412690800418477A-4
3AXD50000645015
Note:
• See also sections:
•
Protecting the drive and the input power cable in short-circuits (page 87)
•
Protecting the drive against thermal overload (page 87)
•
Protecting the input power cable against thermal overload (page 88).
• In multicable installations, install only one fuse per phase (not one fuse per conductor).
• Fuses with higher current rating than the recommended ones must not be used. Fuses
with lower current rating can be used.
• Alternative fuses can be used if they meet certain characteristics. For acceptable fuses,
see the technical note (3AXD50000645015).
