ABB ACQ580-34 - Cooling Fans

IllustrationOrdering codeKit codeQty
Enclosure width /
Degree of protection
3AXD50000010362A-4-X-0672800 mm / IP54 (UL)
Instruction code: 3AXD50000010284
Note: Fan to be ordered separately
Cooling fans
Two cooling fans must be installed inside the air outlet compartment to ensure sufficient
cooling of the cabinet.
Ordering codeQtyComponentEnclosure width /
Degree of protection
DataName
3AXD500000005142R2E225-RA92-17 (230 V)Fan800 mm / IP20, IP42
3AXD500000008822MSB MKP 3,5/603/E1679Capacitor
3AXD500000007232SPB2,5/7 (2.5 mm
2
, 12AWG)Connector
3AXD500000007242SC 2,5-RZ/7 (2.5 mm
2
, 12AWG)Connector
3AXD500000069342RB4C-355/170Fan800 mm / IP54
3AXD500000069592MSB MKP 6/603/E1679Capacitor
3AXD500000007232SPB2,5/7 (2.5 mm
2
, 12AWG)Connector
3AXD500000007242SC 2,5-RZ/7 (2.5 mm
2
, 12AWG)Connector
Control panel mounting platforms
Ordering codeKit
3AXD50000217717DPMP-04 control panel mounting platform
3AXD50000240319DPMP-05 control panel mounting platform
Retrofit accessory kits
Ordering codeOption codeKit
3AXD50000026145+E208Common mode filter kit (included as standard)
3AXD50000019542+H370Full size cable connection terminals for input power cables
Ordering information 163
