Operation principle and hardware
description
Contents of this chapter
This chapter describes the operating principle and construction of the drive module.
Operation principle
The ACQ580-34 is an ultra-low harmonic drive module for controlling asynchronous AC
induction motors, permanent magnet motors in open loop control and synchronous reluctance
motors.
The drive includes a line-side converter and a motor-side inverter. The parameters and
signals for both of them are combined into one primary user program.
