Inside the logic relay
242
1SVC 440 795 M0100
Loading a circuit diagram from the memory module
X Select the CARD r DEVICE menu option.
X Press OK to confirm the prompt if you want to delete the
CL memory and replace it with the module content.
Press ESC to go back one menu.
Deleting a circuit diagram on the memory module
X Select the DELETE CARD menu option.
X Press OK to confirm the prompt and to delete the module
content.
Press ESC to cancel.
DEVICE-CARD
CARD-DEVICE
DELETE CARD
h
Attention!
Once you have started the CARD r DEVICE transfer, the
following operation is initiated:
• The RAM of the device is loaded from the module.
• The internal program memory is cleared.
• The data is written from the module to the internal
retentive program memory.
This is carried out in blocks. A complete program is not
transferred to the RAM for space reasons.
If an invalid program or an interruption occurs during the
read or write operation, CL-LSR/CL-LST or CL-LMR/CL-LMT
loses the program in the internal memory.
DELETE ?
