68 EL3000 CONTINUOUS GAS ANALYZERS | OI/EL3000-EN REV. D
… 5 Installation
… Position and design of the gas connections
Magnos28: Gas Connections
Supplementary information
⅛ NPT female thread (stainless steel 1.4305)
Connection of hose lines:
straight screw-
in socket (PP) with hose nozzles
for hoses with inside diameter 4 mm
(included in scope of delivery)
Connection of piping:
screw-in fittings
(not included in scope of delivery)
—
Note
The sample gas inlet of Magnos28 can be connected to the sample gas output of Limas23 at the factory or have a separate sample
gas path without connection to Limas23.
