EL3060 CONTINUOUS GAS ANALYZERS | OI/EL3060-EN REV. A 133
Status messages
No. Status Message Reaction/Troubleshooting
110 A S a The instrument is booting.
116 A S a The Profibus module is installed in the
wrong slot! The interface is therefore not
operative. Please install the Profibus module
in slot X20/X21.
Install the Profibus module in slot X20/X21.
119 A S iQ The configuration could not be loaded! This
instrument is therefore currently not con-
figured. Please load a configuration using
TCT.
This instrument is therefore currently not
configured. Notify service if this occurs
again.
120 F a The maintenance switch is ON.
121 aL The limit value has alarm status.
122 A S a The IO module is defective. Exchange the IO module.
123 A S a Communication error while accessing the IO
module.
Exchange the IO module.
124 iQ The configuration data was corrupt! The
configuration was restored using the back-
up data.
125 a The limit value has alarm status.
126 W a The QAL3 data store is full. Please read out
the data.
Export QAL3 data.
127 W a The drift values exceed the QAL3 limits. Repeat the calibration. Maintenance of AMS
required.
250 A S aQ The analyzer could not be found! Check the connectors and cabling.
251 A S aQ The connection to the analyzer has been
lost!
Check the connectors and cabling.
252 A S aL The EEPROM data of the analyzer is defec-
tive!
Check the configuration with TCT.
253 A S aL Communication with the analyzer is faulty! Check the connectors and cabling.
254 A S a The boot program of the analyzer is defec-
tive! Notify Service!
Notify Service.
255 A S a The program of the analyzer is defective!
Notify Service!
Notify Service.
300 A S aL No new measured values from the ana-
log/digital converter.
Notify Service.
301 A S a The measured value exceeds the value range
of the analog/digital converter.
Check the sample gas concentration. Check
connectors in the gas analyzer. Notify Ser-
vice.
302 W aQ The offset drift exceeds half the permissible
range.
Monitor the drift. The measured value is
valid as long as the drift remains below the
value specified in the measurement data. As
soon as the drift exceeds this value, notify
Service.
303 A S aQ The offset drift exceeds the permissible
range.
Notify Service. Carry out a basic calibration
(with TCT).
