134 EL3060 CONTINUOUS GAS ANALYZERS | OI/EL3060-EN REV. A
No. Status Message Reaction/Troubleshooting
304 W aQ The amplification drift exceeds half the
permissible range.
Monitor the drift. The measured value is
valid as long as the drift remains below the
value specified in the measurement data.
The detector concerned will have to be ex-
changed in the near future. Manually cali-
brate the indicated detector at the zero and
end point. Permissible range: 50 % of the
detector sensitivity. As soon as the drift
exceeds this value, notify Service.
305 A S aQ The amplification drift exceeds the permis-
sible range.
Exchange the detector concerned. Notify
Service. Carry out a basic calibration (with
TCT).
306 W aQ The offset drift between two calibrations
exceeds the permissible range.
Manually calibrate the indicated detector at
the zero point. (This message is generated
by automatic calibration.) Permissible
range:15% of the smallest installed measur-
ing range; 6% of the smallest installed
measuring range for measurements on
plants subject to approval pursuant to the
27th and 30th Federal Regulation on Immis-
sions
307 W aQ The amplification drift between two calibra-
tions exceeds the permissible range.
Manually calibrate the indicated detector at
the end point. (This message is generated
by automatic calibration.) Permissible range:
15% of the sensitivity; 6% of the sensitivity
for measurements on plants subject to ap-
proval pursuant to the 27th and 30th Federal
Regulation on Immissions
308 A S aQ A calculation error occurred during calcula-
tion of the measured value.
Switch the power supply off and on. Notify
Service.
309 W a The temperature regulator is defective. Notify Service.
310 W a The temperature correction has been turned
off for this component because the meas-
ured temperature value is invalid.
Notify Service.
311 A S a The pressure regulator is defective. See status message of the pressure detec-
tor concerned
312 W a The pressure correction has been turned off
for this component because the measured
pressure value is invalid.
Notify Service.
313 W a Cross-sensitivity correction is not possible
for this component because the correction
value is invalid.
Check with TCT.
314 W a Carrier gas correction is not possible for this
component because the correction value is
invalid.
Check with TCT.
315 W aL No new measured values from the ana-
log/digital converter.
Notify Service.
316 W a The measured value exceeds the value range
of the analog/digital converter.
Notify Service.
317 W a A calculation error occurred during calcula-
tion of the measured value.
Notify Service.
