Inspecting, mechanical stop pin
Use this procedure to inspect the axis-1 mechanical stop pin.
NoteAction
DANGER
Turn off all:
• electric power supply
• hydraulic pressure supply
• air pressure supply
to the robot, before entering the robot working
area.
1
Inspect the axis-1 mechanical stop pin.2
If the mechanical stop pin is bent or damaged, it
must be replaced.
Note
The expected life of gearboxes can be reduced
after collision with the mechanical stop.
140 Product manual - IRB 6620
3HAC027151-001 Revision: T
© Copyright 2006-2018 ABB. All rights reserved.
3 Maintenance
3.3.9 Inspecting the axis-1 mechanical stop pin
Continued
