ABB IRB 6620 - Page 348

Art. no.QtyDescription
3HAC15521-12Guide pins M10 x 100
3HAC15521-22Guide pins M10 x 150
3HAC14459-11Lifting tool, motor ax 1
3HAC026061-0011Lifting tool, motor ax 2, 3
3HAC14972-12Removal tool, motor M10x
Fits motors, axes 6.
Fits motors axes 1, 2 and 3.Removal tool, motor M12x
3HAC17105-11Rotation tool
-1Standard toolkit (content described in sec-
tion Standard tools on page 346)
Lifting tool
The following table specifies the lifting tools required during several of the service
procedures. The tools may be ordered separately and are also specified directly
in concerned instructions in the product manual.
Art. no.QtyDescription
3HAC026597-001Lifting tool
Hoisting block
Lifting chain (used together with the hoisting
block)
3HAC15535-1Support, base and gear axis 1
3HAC15556-1Lifting tool, gearbox axis 1
3HAC025333-005Lifting eye (used together with lifting tool
3HAC 15556-1)
3HAC025214-001Lifting tool, gearbox
3HAC022637-001Guide pins, M12x130
Guide pins, M16x
3HAC14457-1Lifting eye, M16
Lifting eye, M20
Crank
348 Product manual - IRB 6620
3HAC027151-001 Revision: T
© Copyright 2006-2018 ABB. All rights reserved.
7 Reference information
7.6 Special tools
Continued
