7 Repair
7.3 Replacement of System LED Board, ALED
134 3HNA009834-001 en Rev.06 Product Manual, Control Cabinet IRC5P
Refitting The procedure describes how to re-install the system LED board.
WARNING! Refitting activities must only be performed when controller is switched
‘off’ and all safety precautions under ‘Removal’ have been read.
1. Place the board in position over the attachment holes. Make sure the orientation
of the board is correct.
2. Install attachment screws and tighten.
3. Insert connectors.
4. Close controller front door.
