7 Repair
7.12 Replacement of Compact Flash
152 3HNA009834-001 en Rev.06 Product Manual, Control Cabinet IRC5P
3. Make sure that the two status LEDs on the computer unit just above the flash
disk are extinguished.
4. Grip the compact flash card as shown in Figure 77.
5. Carefully pull out the card.
Refitting The procedure describes how to install the compact flash in the computer unit.
WARNING! Refitting activities must only be performed when controller is switched
‘off’ and all safety precautions under ‘Removal’ have been read.
1. Carefully position the compact flash card in the guides which are located at the
inner end of the compact flash slot.
Important: Be careful when inserting the compact flash. If you loose the grip, the
card may fall down, inside the computer unit.
2. Gently glide the card into position against the connector.
CAUTION! Be careful when performing next step as you may damage the contact
pins in the connector.
3. Make sure that the card is correctly positioned and then place one finger at each
end of the card as shown in Figure 77. Then press the card carefully into the
connector.
4. Close controller front door.
