4 Technical Specifications
Product Manual, Control Cabinet IRC5P 3HNA009834-001 en Rev.06 33
4.2 Controller Specifications
Inputs and Outputs Different types of distributed I/O units can be installed. The following table shows
the maximum number of physical signals that can be used on each unit. For more
details, see technical specifications for relevant unit in ‘Unit Description, IRC5P’,
Distributed I/O.
*1) The digital signals are supplied in groups, each group having 8 inputs or outputs.
*2) To calculate the number of logical signals, add 2 status signals for RIO unit and 1 for
Interbus-S, Profibus DP and CC-Link.
*3) Selectable voltage or current.
*4) Encoder inputs or digital inputs.
*5) The system has a limitation of 255 input/output signals for one unit. However, when
using the DSQC 378 together with the IPS, you can define 368 (*2) inputs and 368
outputs.
Type Name Function
AD Combi I/O DSQC 651 8 digital in / 8 digital out / 2 analog out
Digital I/O DSQC 652 16 digital in / 16 digital out *1
Relay I/O DSQC 653 8 digital in / 8 digital out
Digital I/O 120 VAC DSQC 654 8 digital in / 8 digital out
Analog interface board ANIB 8 analog in / 4 analog out / 4 digital out
Digital Sensor interface brd. DSIB 16 namur sensor inputs
Pressure sensor interf. brd. PSIB 8 pressure sersor inputs
Process I/O PIO 16 *4 digital in / 8 digital out /16 analog in *3 /12
analog out *3 / 4 encoder inputs *4
Digital I/O DSQC 328 16 digital in / 16 digital out
Analog I/O DSQC 355 4 analog in / 4 analog out
Profibus DP slave DSQC 352 128 *2 digital in / 128 digital out
Allen-Bradley Remote I/O DSQC 350 128 *2 digital in / 128 digital out
Interbus-S slave DSQC 351 64 *2 digital in / 64 digital out
CC-Link DSQC 378 176 *5 digital in / 176 digital out
Encoder unit DSQC 377 2 encoders / 2 sync signals
