Menu tree - Appendix
Version 1.0-00
1MRK 580 158-XEN
Page 3 - 62
REx5xx REx5xx/Config
.Config/FuncInp .FuncInp/FuseF
SIGNAL LIST
Disturb Report
FunctionInputs Trip FUSE-MCB All signals in signal
Service Report Slot11-BIM1 (*) Differential
FUSE-DISC list are grouped
Settings Slot13-IOM2 (*) HighSpeed .FuncInp/HiSetOC
under function sub-
Terminal Status Slot15-BOM3 (*) GFC
HII--BLKTR menus
Configuration Slot17-BOM4 (*) Zone 1 .FuncInp/UnVolt see SIGNAL LIST B
Command Slot19-BIM5 (*) Zone 2
UUVT-VTSU
Test Identifiers Zone 3 UUVT-BLOCK
AnalogInputs Zone 4 .FuncInp/Stub
I/O-modules Zone 5 S TUB-DISC
(*) This is an example
Time ZCommunication .FuncInp/LOVolt
BuiltInMMI PhaseSelection LOV--BC
SPAComm PowerSwingBlck LOV--VTSU
LONComm SwitchOnToFlt .FuncInp/BrkFail
Differential EarthFault BFP--STL1
DisturbReport SensitiveEF BFP--STL2
FuseFailure BFP--STL3
HiSetOverCurr BFP--ST3PH
UnderVoltage .FuncInp/PolDisc
Stub PDP--POLDISC
LossOfVoltage PDP--BC
BreakerFailure PDP--BLOCK
PoleDiscord PDP--GTRIP
AutoRecloser1 .FuncInp/AR01
SynchroCheck1 AR01--START
TimeOverCurr AR01--ON
TripSuperv AR01--OFF
ActiveGroup AR01--CBREADY
Test AR01--CBCLOSED
AND AR01--INHIBIT
OR AR01--PLCLOST
Timer AR01--WAIT
Pulse AR01--SYNC
INV AR01--TRSOTF
SR AR01--TPTRIP
.FuncInp/SyncCh1
SYN1-BLOCK
SYN1-FD1OPEN
SYN1-FD1CLD
SYN1-FD2OPEN
SYN1-FD2CLD
SYN1-CB1OPEN
SYN1-CB1CLD
SYN1-CB2OPEN
SYN1-CB2CLD
SYN1-CB3OPEN
SYN1-CB3CLD
SYN1-UB1FF
SYN1-UB1OK
SYN1-UB2FF
SYN1-UB2OK
SYN1-UF1FF
SYN1-UF1OK
SYN1-UF2FF
SYN1-UF2OK
SYN1-VTSU
