Configurable logic
Version 1.0-00
1MRK 580 161-XEN
Page 4 - 34
Fig. 16 Simplified terminal diagram of the Pulse function
Fig. 17 Simplified terminal diagram of the Exclusive OR function
Fig. 18 Simplified terminal diagram of the Set-Reset function
Fig. 19 Simplified terminal diagram of the MOVE First (MOF) func-
tion
INPUT
T
OUT
(X80161-16)
TPnn
Pulse
INPUT1
INPUT2
OUT
NOUT
(X80161-17)
XOnn
XOR
SET
RESET
OUT
NOUT
(X80161-18)
SRnn
SR
OUTPUT2
OUTPUT3
OUTPUT4
OUTPUT5
OUTPUT6
OUTPUT1
OUTPUT7
OUTPUT8
OUTPUT9
OUTPUT10
OUTPUT11
OUTPUT12
OUTPUT13
OUTPUT15
OUTPUT16
OUTPUT14
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
INPUT7
INPUT8
INPUT9
INPUT10
INPUT11
INPUT12
INPUT13
INPUT14
INPUT15
INPUT16
(X80161-19)
MOFn
MOVE
