ABB Network Partner AB
Apparatus control
Version 1.0-00
1MRK 580 150-XEN
Page 6 - 74
BDxx-SEL6 Apparatus 6 is selected after reservation
acknowledgement from other bays
BDxx-SEL7 Apparatus 7 is selected after reservation
acknowledgement from other bays
BDxx-SEL8 Apparatus 8 is selected after reservation
acknowledgement from other bays
BDxx-RE A reservation has been made in this bay
BDxx-RE_BAYS Request for reservation of other bays
BDxx-ACK_T_B Acknowledgement to other bays that this
bay is reserved
BDxx-FDB_SEL1 Correct selection relay is energized for
apparatus 1
BDxx-FDB_SEL2 Correct selection relay is energized for
apparatus 2
BDxx-FDB_SEL3 Correct selection relay is energized for
apparatus 3
BDxx-FDB_SEL4 Correct selection relay is energized for
apparatus 4
BDxx-FDB_SEL5 Correct selection relay is energized for
apparatus 5
BDxx-FDB_SEL6 Correct selection relay is energized for
apparatus 6
BDxx-FDB_SEL7 Correct selection relay is energized for
apparatus 7
BDxx-FDB_SEL8 Correct selection relay is energized for
apparatus 8
BDxx-BINPERR Indication for binary input board error
BDxx-BOUTERR Indication for binary output board error
BDxx-AU_OP_V1 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 1
BDxx-AU_OP_V2 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 2
BDxx-AU_OP_V3 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 3
BDxx-AU_OP_V4 Automatic operation permitted, i.e. the oper-
ator place selector is not in Local position,
the apparatus is not reserved or not manual
selected for apparatus 4
Table 8: Output signals for BAYCOND
OUT: DESCRIPTION:
