Interlocking
ABB Network Partner AB
1MRK 580 151-XEN
Page 6 - 209
Version 1.0-00
IMxx-Q51ITL Switching of Q51 is forbidden
IMxx-Q52REL Switching of Q52 is allowed
IMxx-Q52ITL Switching of Q52 is forbidden
IMxx-Q53REL Switching of Q53 is allowed
IMxx-Q53ITL Switching of Q53 is forbidden
IMxx-Q9REL Switching of Q9 is allowed
IMxx-Q9ITL Switching of Q9 is forbidden
IMxx-Q8REL Switching of Q8 is allowed
IMxx-Q8ITL Switching of Q8 is forbidden
IMxx-Q2OPTR Signal is 1 if Q2 is open
IMxx-Q2CLTR Signal is 1 if Q2 is closed
IMxx-VPQ2TR Switch status of Q2 is valid (open or closed)
Table 24: Output signals for BH_LINE_B
OUT: DESCRIPTION:
