Command function
ABB Network Partner AB
1MRK 580 165-XEN
Page 6 - 217
Version 1.0-00
7 Appendix
7.1 Terminal diagrams
Fig. 5 Simplified terminal diagram of the Single Command function
Fig. 6 Simplified terminal diagram of the Multiple Command function
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
OUT7
OUT8
OUT9
OUT10
OUT11
OUT12
OUT13
OUT14
OUT15
OUT16
SingleCmdFunc
CmdOut1
CmdOut2
CmdOut3
CmdOut4
CmdOut5
CmdOut6
CmdOut7
CmdOut8
CmdOut9
CmdOut10
CmdOut11
CmdOut12
CmdOut13
CmdOut14
CmdOut15
CmdOut16
MODE
(X80165-5)
CDxx
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
OUT7
OUT8
OUT9
OUT10
OUT11
OUT12
OUT13
OUT14
OUT15
OUT16
MultCmdFunc
CmdOut
MODE
VALID
INTERVAL
(X80165-6)
CMxx
