ABB Network Partner AB
Command function
Version 1.0-00
1MRK 580 165-XEN
Page 6 - 220
CMDOUT8 13 characters string User name for Output 7, to be set from CAP
531 or from SMS for REL 531
CMDOUT9 13 characters string User name for Output 8, to be set from CAP
531 or from SMS for REL 531
CMDOUT10 13 characters string User name for Output 9, to be set from CAP
531 or from SMS for REL 531
CMDOUT11 13 characters string User name for Output 10, to be set from
CAP 531 or from SMS for REL 531
CMDOUT12 13 characters string User name for Output 11, to be set from
CAP 531 or from SMS for REL 531
CMDOUT13 13 characters string User name for Output 12, to be set from
CAP 531 or from SMS for REL 531
CMDOUT14 13 characters string User name for Output 13, to be set from
CAP 531 or from SMS for REL 531
CMDOUT15 13 characters string User name for Output 14, to be set from
CAP 531 or from SMS for REL 531
CMDOUT16 13 characters string User name for Output 15, to be set from
CAP 531 or from SMS for REL 531
MODE 0=Off, 1=Steady,
2=Pulse
Output mode common for the command
block, to be set from CAP 531 or from SMS
for REL 531
Table 3: Setting table for Single Command function No. xx
PARAMETER: SETTING RANGE: DESCRIPTION:
Table 4: Setting table for Multiple Command function No. xx
PARAMETER: SETTING RANGE: DESCRIPTION:
CMDOUT 19 characters string Common user name for the outputs in the
multiple command block, to be set from
CAP 531
MODE 0=Off, 1=Steady,
2=Pulse
Output mode common for the command
block, to be set from CAP 531
INTERVAL 0-60 s Time interval for supervision of received
data
