ABB Network Partner AB
Direct current measuring unit
Version 1.0-00
1MRK 580 154-XEN
Page 7 - 16
Note: (a) is referred to the user-defined parameter Unit, where the user
can write the unit of the measuring converter input measuring quantity.
The setting parameters are the same for all measuring channels (m = 1...6)
on all mA input modules (n = 1...6).
MaxValue (-1000.00 - 1000.00)(a) Determines the maximum value of the measuring transducer pri-
mary measuring quantity, which corresponds to the maximum per-
mitted input current I_Max
I_Min (-20.00 - 20.00)mA Determines the minimum permitted input current to the measuring
channel
Table 3:
PARAMETER: SETTING RANGE: DESCRIPTION:
