Disturbance recorder
ABB Network Partner AB
1MRK 580 141-XEN
Page 7 - 71
Version 1.0-00
The recordings can be divided into two parts, the header and the data part.
The data part contains the numerical values for the recorded analogue and
binary channels. The header contains clearly written basic information on
the disturbance. A part of this information is also used by REVAL to
reproduce the analogue and binary signals in a correct and user-friendly
way. Such information is, primary and secondary instrument transformer
ratings.
This information is included in the header:
Table 1 is a summary. For detailed information, see the User’s Guide for
REVAL (1MRK 501 003-UEN).
Table 1: Contents of the header
Type of information
Parameter
Stored in
parameter
database
Stored with
disturbance
General
Station, object & unit ID x -
Date and time - x
Sequence number - x
CT earthing x -
Time synchronisation source x -
Recording times tPre, tPost, tLim - x
Pre-fault Uph-ph, I (RMS) - x
Trig signal and test mode flag - x
Analogue signals
Signal name x -
Primary and secondary instr. transformer rating x -
Undertrig: level and operation x -
Overtrig: level and operation x -
Undertrig status at time of trig - x
Overtrig status at time of trig - x
Instantaneous Uph-0 at time of trig - x
Instantaneous Iph-0 at time of trig - x
Uph-0/Iph-0 (RMS) before trig (pre-fault) - x
Uph-0/Iph-0 (RMS) after trig (fault) - x
Binary signals
Signal name - x
Type of contact (trig level) x -
Trig operation x -
Signal status at time of trig - x
Trig status at time of trig - x
