1. Select Main Menu/Configuration/HMI/FB naming convention and press
.
2.
Change the display symbols with or .
3.
Press to confirm the selection.
The IED has to be rebooted if the WHMI display symbols are
changed. With the LHMI, the change takes effect immediately.
8.5.2.4 Changing the default view
The default view of the display is Measurements unless set otherwise.
1.
Select Main menu/Configuration/HMI/Default view and press .
2.
Change the default view with or .
3.
Press
to confirm the selection.
8.5.2.5 Setting system time and time synchronization
1.
Select Main Menu/Configuration/Time/System time and press .
2.
Select the parameter with or .
3.
Press , change the value with or and press again.
4. Repeat steps 2 and 3 to set the rest of the system time parameters.
5. Select Main Menu/Configuration/Time/Synchronization/Synch source and
press
.
6.
Select the time synchronization source with or .
7.
Press to confirm the selection.
Setting daylight saving time
The IED can be set to determine the correct date for the DST shift every year. The
UTC time is used to set the DST.
1. Set the DST on day and DST off day parameters to define on which week day
the time shift occurs.
2. Set the DST on date and DST off date parameters to define on which month and
week the time shift occurs.
The DST on/off date must precede the selected DST on/off day and be within
the same week as the DST shift.
